This units are designed for Small to Mid-sized Wind Turbine up to 1MW power. It's also called electrical rotary joint.
¡ö 3 circuits models
¡ö Precious metal contacts
¡ö 20, 40, 60 amps rings
¡ö Precision ball bearings for long life
¡ö Speeds up to 300 rpm continuous
¡ö Compact size
¡ö Flying leads
¡ö Sealed units available
Number of Circuits 3
Rotary Speed 0-300 rpm
Voltage Rate 380 VAC/ 240VDC
Current Rate 20, 40, 60 amps per circuit
Temperature -40¡æ to +80¡æ
Contact Material Precious metal
Lead Size AWG14(20A) PE
Lead Lengths 500 MM (longer available)
Torque Force Approx. 50.0 cmg per circuit?
Through Bore ¦µ25.4 mm, 38.1 mm, 50.0 mm, 60.0 mm
Noise ¡Ü10m¦¸
Length =L
Current Rate KYW25 KYW38 KYW50 KYW60
20A 55.0mm 55.0mm 70.0mm 78.0mm
40A 55.0mm 55.0mm 70.0mm 78.0mm
60A -   70.0mm 78.0mm
